characteristics:
●adopting most advanced inverter technology and importing igbt, good stiffness of the arc, suitable for pipe welding
●have mma/mig/mag functions, can do welding of solid wire and flux core wire.
●super voltage compensation makes constant welding current even if tough power net.
●built-in electronic inductance function, welding stable, less spark, deep welding pool, bright welding seam.
●the most cost-effective industrial mig welding machine in china.
parameters:
|
model |
mig350c |
mig500c |
||
|
power voltage(v) |
ac380v±15% |
ac380v±15% |
||
|
frequency (hz) |
50/60 |
50/60 |
||
|
rated input power（kva） |
mig：14 |
arc：15 |
mig：24 |
arc：25 |
|
output current current (a) |
68 |
75 |
||
|
output current current (a) |
mig:60-350 |
arc：60-350 |
mig：60-500 |
arc:60-500 |
|
wire feeder |
separated |
separated |
||
|
spool(kg) |
15 |
15 |
||
|
wire diameter (mm) |
0.8/1.0 |
0.8/1.0 |
||
|
plate thickness (mm) |
0.6above |
0.6above |
||
|
duty cycle (%) |
60 |
60 |
||
|
efficiency（%） |
85 |
85 |
||
|
power factor |
0.93 |
0.93 |
||
|
insulation class |
f |
f |
||
|
housing protection class |
ip21 |
ip21 |
||
|
weight (kg) |
36 |
40 |
||
|
dimension(l*w*h) |
530*280*460 |
530*280*460 |
||
standard accessories:
mig350c
●3 meter 35mm2 earth cable with 500a earth clamp
●3 meter 35mm2 welding cable with500a electrode holder
●3 meter mig torch qtb-350a
