characteristics:
●adopts advanced inverter technique, high working frequency, small volume, lightweight, easy to carry.
●adopts high frequency boosted voltage arc striking and pulse hot arc striking, easy for arc strking.
●unique over voltage protection, over heat protection and over current protection function.
●has unique output characteristic, more suitable for filler wire welding with satisfactory welding result.
●simple structure, excellent workmanship, reliable and durable, easy to maintain.
parameters:
|
model
|
tig160s |
tig200s |
tig250s |
tig300s |
|
input voltage (v) |
single-phase ac220v±15% |
single-phase ac220v±15% |
single-phase ac220v±15% |
three-phase ac380v±15% |
|
frequency（hz） |
50/60 |
50/60 |
50/60 |
50/60 |
|
rated input current（a） |
20 |
28 |
40 |
12.7 |
|
no-load voltage (v) |
40 |
41 |
46 |
95 |
|
outputcurrent range(a) |
10～160 |
10～200 |
10～250 |
10～300 |
|
rated output voltage (v) |
16.4 |
18 |
20 |
22 |
|
duty cycle (%) |
60 |
60 |
60 |
60 |
|
no-load loss (w) |
40 |
40 |
40 |
60 |
|
arc striking way |
hf |
hf |
hf |
hf |
|
efficiency (%) |
80 |
80 |
80 |
85 |
|
power factor |
0.73 |
0.73 |
0.73 |
0.93 |
|
insulation grade |
f |
f |
f |
f |
|
housing protection class |
ip21 |
ip21 |
ip21 |
ip21 |
|
net weight (kg) |
9 |
9 |
9 |
19 |
|
dimension (mm) |
390*150*240 |
390*150*240 |
390*150*240 |
480*203*320 |
standard accessories:
tig200s
●3 meter 16mm2 earth cable with 300a earth clamp
●4 meter tig torch wp-26
