productos
soldadoras mig/mag del inversor-integrado alimentacion del alambre
sale tel：0755-27264889
sale fax：0755-27264785
qq：
thank you to place an order with us we will in the shortest possible time with you.
characteristics:
●multi-functional,mma/mig/mag welding process combined.
●igbt inverter technology,current-mode control,reliable quality and stable performance
●close-loop feedback, constant voltage output, super ability of voltage anti-fluctuation
●electronic reactor control, stable welding process , little splash, deep molten pool,
perfect welding formation
●arc striking slow wire feeding, fixed burn back time, ensure arc starting rate
●applicable thickness 0.6 mm above plate welding
●small volume, light weight, simple operation, economic and practical
●diameter at 0.6 mm wires can realize the stable 30a welding, and can be widely
used in automobiles, steel doors and windows, furniture etc
●cost-effective, can completely replace traditional tap welder
parameters:
|
model |
mig-200c(g25) |
mig-200c(g26) |
||
|
power voltage(v) |
ac220v±15% |
ac220v±15% |
||
|
frequency (hz) |
50/60 |
50/60 |
||
|
rated input power（kva） |
mig：8.2 |
arc：6.7 |
mig：8.2 |
arc：6.7 |
|
output current current (a) |
58 |
58 |
||
|
output current current (a) |
mig:35-200 |
arc：20-180 |
mig：35-200 |
arc:20-180 |
|
wire feeder |
built-in |
built-in |
||
|
spool(kg) |
15 |
5 |
||
|
wire diameter (mm) |
0.8/1.0 |
0.8/1.0 |
||
|
plate thickness (mm) |
0.6 above |
0.6 above |
||
|
duty cycle (%) |
60 |
60 |
||
|
efficiency（%） |
80 |
80 |
||
|
power factor |
0.73 |
0.73 |
||
|
insulation class |
f |
f |
||
|
housing protection class |
ip21s |
ip21s |
||
|
weight (kg) |
23 |
22 |
||
|
dimension(l*w*h) |
460*220*370 |
460*220*370 |
||
standard accessories:
mig200(g25)/mig200(g26)
●3 meter 16mm2 earth cable with 300a earth clamp
●3 meter mig torch mb-24
